Multi Gas Portable Gas Analyser

Display

2.31 inch 320X240 high-definition color screen display

Detection method

Built in pump suction, flow 500 ml / min.

Datalogging

10000 samples, can be transferred to PC through USB

Detection accuracy

Less than 3% (F.S.)

Linearity

Less than 2%

Repeatability

Less than 2%

Alarm mode

Sound and light alarm, vibration alarm, visual alarm

Response time: T90

20 seconds

Recovery time

< 30 seconds

Operating power

DC3.6V

Battery capacity

3.6VDC, 4500mA

Charger

USB Charger

Working temperature

- 40℃ to +70℃

Working humidity

0-95% RH

Sample gas temperature

-40℃ to C20+70℃

Explosion-proof type

EX ia IIC T4

Protection degree

IP65，Dustproof, waterproof splash

Dimension

160×70×28mm (L×W×H)

Weight

300g

Standby hours

8 to 10

Time to fully charge

4 hours

Sr. No.

Application

Model

Detection Gas

Range

Resolution

1.

Bio Gas

PGABG4

Carbon dioxide (CO2),

CO2: 0-20% vol

CO2: 1 % / 0.1 % / 0.01%

Oxygen (O2),

O2: 0-30% vol

O2: 1 % / 0.1 % / 0.01%

Methane (CH4),

CH4: 0-100% lel

CH4: 1 % / 0.1 % / 0.01%

Hydrogen Sulphide (H2S)

H2S: 0-2000 ppm

H2S: 1 ppm

2.

Bio Gas

PGABG3

Carbon dioxide (CO2)

CO2: 0-20% vol

CO2: 1 % / 0.1 % / 0.01%

Methane (CH4),

CH4: 0-100% lel

CH4: 1 % / 0.1 % / 0.01%

Hydrogen Sulphide (H2S)

H2S: 0-2000 ppm

H2S: 1 ppm

3.

Bio Gas

PGABG2

Methane (CH4),

CH4: 0-100% lel

CH4: 1 % / 0.1 % / 0.01%

Hydrogen Sulphide (H2S)

H2S: 0-2000 ppm

H2S: 1 ppm

4.

Cold Storages

PGACS3

Oxygen (O2)

0 – 30 % vol

O2: 1 % / 0.1 % / 0.01%

Carbon dioxide (CO2)

0 – 20 % vol

CO2: 1 % / 0.1 % / 0.01%

Ethylene (C2H4)

0 – 2000 ppm

C2H4: 1 ppm

5.

Cold Storages

PGACS2A

Oxygen (O2)

0 – 30 % vol

O2: 0.1 % / 0.1 % / 0.01%

Ethylene (C2H4)

0 – 2000 ppm

C2H4: 1 ppm

6.

Cold Storages

PGACS2B

Carbon dioxide (CO2)

0 – 20 % vol

CO2: 1 % / 0.1 % / 0.01%

Ethylene (C2H4)

0 – 2000 ppm

C2H4: 1 ppm

7.

Cold Storages

PGACS2C

Carbon dioxide (CO2)

0 – 20 % vol

CO2: 1 %/ 0.1% / 0.01%

Oxygen (O2)

0 – 30 % vol

O2: 1 % / 0.1 % / 0.01%
